No compromise

No need to compromise: with MasterLine 10 you can have it all. This new system unites the best of all worlds: unlimited design freedom combined with ultimate comfort and optimal insulation performance.

MasterLine 10 windows are designed for the building trends of today and tomorrow: low energy building, maximum daylight access, superb performance and safe homes (burglar resistance class 3).

The product offering of MasterLine 10 windows is truly unique in its applicability: inward opening windows, a full range of transoms and frames, connection profiles with Sliding and Curtain Wall systems, but also the design freedom that is offered with the Renaissance and Deco profile range.

The windows are offered with a Passive House certificate! The combination of all these features makes MasterLine 10 the ideal solution for domestic as well as public projects.

── Download Catalogue

Performance

Thermal insulation

Uf-value down to 0.76 W/m²K

Acoustic performance

Rw(C;Ctr) = 46 (-1; -4) dB

Air tightness

Up to 600 Pa (class 4)

Wind load resistance

Up to 1600 Pa (class 4)

Water tightness

Up to 900 Pa (class E900)

Burglar resistance

Up to RC 3 (EN 1627)

Technical Characteristics

Min. visible width inward opening window

Functional

Renaissance

Deco

Frame
60 mm
60 mm
60 mm

Vent
37 mm
37 mm
37 mm

Min. visible width inward
opening window-door

Frame
60 mm
60 mm
60 mm

Vent
67 mm
67 mm
67 mm

Overall system depth window

Frame
97 mm
107 mm
107 mm

Vent
107 mm
107 mm
107 mm

Rebate height

27 mm
27 mm
27 mm

Glass thickness

Frame
up to 88 mm
up to 88 mm
up to 88 mm

Vent
up to 88 mm
up to 78 mm
up to 78 mm
